Welcome to the official website of ZTEC HID - ZtecHID.com, a division of ProJDM, Inc.. We are the No.1 source for your aftermarket HID kits! Xenon HID worlds is one of the largest distributors of the High Intensity Discharged lighting system in North America. Our base located at Los Angeles, Southern California. We guarantee to bring you the highest quality Xenon HID Kit at lowest price. Xenon HID Worlds make HID lighting affordable to everyone and for all your vehicle needs. Every component included in our HID kits are guaranteed to be authentic and in brand new condition, ZtecHID.com does not sell imitations or refurbished products!



Xenon HID High Intensity Discharged Conversion Kit Complete Set

Xenon HID Conversion Kit

Details

SkuXenon-HID-Kit
Weight5.00 lbs
Price: $125.00

Options

Bulb Size

Color Temp

Additional Pair of Bulbs

Relay Harness (Recommended)

Quantity

Add to cart


Detailed Images Features Specifications Applications

[ Click Image to Enlarge ]

This Xenon Headlight HID High Intensity Discharged Kit Include:

  • Ballast x 2
  • Light Bulb x 2
  • Ballast Bracket x 2
  • Power Cables
  • Screws and Nuts
  • Cable Ties
  • English Instruction Manual
  • Warranty Card w/ 1 Year Warranty

Xenon Bulb Specification:

  • Power consumption: 35watts
  • Luminous flux: 2200~3200
  • Service Life: Up To 3000hrs
  • Mercury purity is 99.999999%
  • Waterproof and vibration resistant
  • Quartz glass of silicon dioxide for headlight protection

Xenon Ballast Specification:

  • Power consumption: 35watts
  • Input Voltage: 9V-16V
  • Working current (Steady state): 3.5 A norm
  • Working temperature: -40 ~ +105
  • Frequency: 400 Hz
  • Waterproof and vibration resistant

Xenon HID Kit Quality Control Passed:

  • 6 hours continuous working aging test.
  • Connection circuit protection test.
  • Short circuit protection test.
  • Lack of voltage protection test.
  • over voltage protection test.
  • Flash light concussion test.
  • Quakeproof capability test.
  • cold, warm boot test.
  • Polarity protection test.
  • EMC anti-jamming test.

Relay Harness (Recommended):

  • Optional part, not necessary, but recommended.
  • Draws power direct from the battery; not vehicle's electrical system.
  • Use the same on/off switch on vehicle.
  • Support maximum of 50w power.
  • Add to kit for $14.99 only. Reg. $24.99, instant $10.00 off.

Due to light reflection of the camera, actual bulb color may look a little different.

If you don't know the bulb size for your cars/trucks,

Click Here to Look-Up

Xenon Headlight Color Temperature 6000K:
Xenon bulbs - 6000K has an approximately 3200lm output, which is 3x the light output of the traditional halogen light and slightly less light output compared to the 5000K. Although it has a bit lesser light output, it emits pure whiter light with very slight and barely noticeable tint of blue and purple.

Xenon Headlight Color Temperature 8000K:
Xenon bulbs - 8000K has an approximately 2900lm output, which is about 3x the light output of the traditional halogen light and slightly less light output compared to the 6000K. While it has a bit lesser light output, it emits bluer light than the 6000K.

Xenon Headlight Color Temperature 10000K:
Xenon bulbs - 10000K has an approximately 2650lm output, which is more than 3x the light output of the traditional halogen light. 10000K produces a deep blue light output approaching violet and the blue is noticeably deeper than the 8000K

Xenon Headlight Color Temperature 12000K:
Xenon bulbs - 12000K has an approximately 2200lm output, which is more than 3x the light output of the traditional halogen light. This color temperature puts out a deep bluish violet light and is deeper colored than the 10000K. It is for customer who is looking for the most extreme and most exotic looking light output.

Please note: most customers have a common misconception that the higher the K (Kelvin temperature) the brighter it gets, but in fact, it is the opposite. The K rating is inversely proportional to the light output, therefore the lower the K the brighter the light output. Also Xenon runs cooler and than your traditional halogen, therefore it will not melt your housing.
